Upon discharge Load fault reported and unit shuts down
Check load for continuity.
Check load for short circuit, unit will shut down if current greater than 4500A.
EOC And HV Fault Lamp Illuminated
Open circuit on HV Charger output. Also:
Open Circuit Energy Storage Capacitor
(Verify by trying alternative power setting)
HV Fault Illuminated, No EOC
HV Charger Faulty, Also:
Short Circuit Energy Storage Capacitor
(Verify by trying an alternative power setting)
No Warning Lamps Illuminated, No EOC and No Output
Press Charge Rate switch, if Unit now operates then Auto Charge Control board is faulty.
Unit Fires On Alternative Key Pulses
Input Key Rate too high.
