APPLIED ACOUSTICS CSPP - Page 52

CSPP Capacitor Charging Unit Operation Manual
CSP-CSPP-8000/2
_________________________________________________________________________________________________________
__________________________________________________________________________________________________________
Page 52 of 59
A
PROTOTYPE
NMM 04/08
N/A
N/A
N/A
REFER TO DRAWING
N/A
NMM 24/04/08
CSPP BANGBOX H.V. WIRING
CSP-CSPP-4012/A
4 x GD110R16
4 x 85HF120
BOARD DIODE
BOARD DIODE
RESISTORS
2 x 10K
KEY THYRISTOR
230VAC FROM CONTROL BOARD
FROM CHARGER
2.6 / 3.6 / 4.0KV
RESISTORS ACROSS CAPACITORS 10MEG-OHM
BOARD
RESISTOR
DUMP
HIGH VOLTAGE OUTPUT
RLB
RLA
VCC
GND
THYRISTOR
CURRENT SENSOR
RESISTORS
3 X 20M
B
CAP
A
CAP
