APPLIED ACOUSTICS CSPP - Page 54

CSPP Capacitor Charging Unit Operation Manual
CSP-CSPP-8000/2
_________________________________________________________________________________________________________
__________________________________________________________________________________________________________
Page 54 of 59
12VDC PSU
HV CHARGER
32uF CAPACITOR
16uF CAPACITOR
CSP-CSPD-5003
CURRENT SENSE PCB
CSP-300P-5020
HV DUMP PCB
CSP-CSPD-5001
HV DIODE PCB
O/P THYRISTOR
MODULE
10KV HV RELAY X 2
A
PROTOTYPE
NM 06/08
REFER TO DRAWING
N/A
NM 03/06/08
CSPP BANGBOX BASE TRAY COMPONENT LOCATION
CSP-CSPP-1001/A
FUSES F1 & F2
AVIP SWITCH
A A
