2 OFF CT70-8
TUBE RING CRIMP
BLACK HEATSHRINK
FEC ( 143-724 )
RED HEATSHRINK
FEC ( 107-480 )
BS6195 TYPE 4 'D' 50mm
3.3KV BLACK CABLE
CABLE LENGTH 1500mm
GEN TOLERANCES:GEN TOLERANCES:
ISSUEISSUE DESCRIPTIONDESCRIPTION
OTHER:OTHER:
DATEDATE
APPD.APPD.
MATERIALS:MATERIALS:
FINISH:FINISH:
NOTESNOTES
DRAWN
APPROVED
CHECKED
REMOVE ALL SHARP EDGES AND BURRS
DRAWN
APPROVED
CHECKED
REMOVE ALL SHARP EDGES AND BURRS
ALL DIMENSIONS IN MILLIMETRESALL DIMENSIONS IN MILLIMETRES
DO NOT SCALEDO NOT SCALE
DATE
DATE
DATE
DATE
DATE
DATE
DRAWING No:DRAWING No:
FILE SAVED AS:FILE SAVED AS:
TITLE:TITLE:
N/A
SCALE 1 : 1
CSPD ISSUE
1 01/07AD
±2mm
SEE DRAWING
IRK
NM
22/01/07
22/01/07
CSP-CSPD-3002/1
JBOX HV CABLE
CSP-D
JUNCTION BOX
H.V. CABLE
3RD ANGLE PROJECTION
H.V. CABLESBLACK SPIRAL WRAP
T5OF-CO
M6 SOLDER TAG
CONNECT TO SCREEN
TWIN SCREENED CABLE
FEC ( 140-463 ) 1700mm
0.062" MOLEX FEMALE
TO H.V. FREE PLUG
TO H.V. FREE PLUG
HEATSHRINK
ASSEMBLY NOTES
1. STRIP INSULATION BACK 12mm
2. SOLDER RING CRIMP TO CABLE
3. CLEAN RING CRIMP THOROUGHLY
4. COVER THE CRIMP WITH HEATSHRINK ( RED OR BLACK )
5. SPRIAL WRAP AROUND CABLES TO FINISH ASSEMBLY
THIS DRAWING IS TO BE USED AS PART OF THE H.V. PLUG ASSEMBLY - CSP-1000-3007/C
THE ASSEMBLY OF THE OTHER END OF THE CABLE ( H.V. PLUG ) MUST BE COMPLETED
BEFORE STARTING ON THIS END OF THE CABLE.
