PERFORM THE REGULAR BRAKING SYSTEM BLEED, AS
DESCRIBED AT THE BEGINNING OF THE CHAPTER.
•
Check the stroke and the sensitivity of both the lever and the brake pedal.
•
If, after bleeding, the pedal or the lever stroke is too long, check that there are no leaks in
the braking system and if everything is ok, continue bleeding operations using Navigator as
described.
•
Detach the bleed hoses and close the bleed screws again to the correct tightening torque.
BRAKE BLEEDING AFTER CALLIPER RE-
PLACEMENT
VEHICLE PREPARATION - The operations are
described for the front system, but they are al-
so valid for both braking systems.
•
Connect the bleed bottles to the bleed
screw of the front calliper and open it.
•
Fully press down the brake lever and
fasten it into position with a locking de-
vice so as to avoid fluid flowing out from
the open system.
•
Close the bleed screws of the front cal-
liper and remove the bleed bottle.
•
Replace the damaged calliper with a
new one.
•
Unlock the brake lever.
•
Remove the cap of the reservoir and fill
it with the new DOT 4 brake fluid up to
the reference "MAX".
•
Refit the cap.
BRAKING SYSTEM BLEEDING (only the new
calliper)
CAUTION
PERFORM THE REGULAR BRAKING SYSTEM BLEED, AS
DESCRIBED AT THE BEGINNING OF THE CHAPTER.
•
Check the stroke and the sensitivity of both the lever and the brake pedal.
•
If, after bleeding, the pedal or the lever stroke is too long, check that there are no leaks in
the braking system and if everything is ok, continue bleeding operations using Navigator as
described.
•
Detach the bleed hoses and close the bleed screws again to the correct tightening torque.
BLEEDING SYSTEM WITH NAVIGATOR
DORSODURO 1200 ABS - ATC Braking system
BRAK SYS - 363
