APRILIA Pegaso 650 I.E. User Manual

ELECTRIC SYSTEM
6 -13
Pegaso 650 I.E.
FAILURE CODE TABLE
Fault
code
Warning light on
Blinks
Failure description
long short
11 YES 1 1 barometric pressure sensor circuit
12 YES 1 2
TPS - throttle position sensor
13 YES 1 3
14 YES 1 4
engine temperature sensor
15 YES 1 5
16 YES 1 6
intake air temperature sensor
17 YES 1 7
21 YES 2 1 wrong pick-up sensor signal sequence
22 YES 2 2 pick-up sensor circuit
23 YES 2 3 sensor power supply circuit, live
24 YES 2 4 battery voltage too low
25 YES 2 5 battery voltage too high
31 YES 3 1
injector 1 circuit 32 YES 3 2
33 YES 3 3
34 YES 3 4
injector 2 circuit 35 YES 3 5
36 YES 3 6
41 YES 4 1
coil 42 YES 4 2
43 YES 4 3
51 YES 5 1
fuel pump relay 52 YES 5 2
53 YES 5 3
54 NO 5 4
coolant temperature indicator
55 NO 5 5
61 YES 6 1
injection relay 62 YES 6 2
63 YES 6 3
64 NO 6 4
CALIFORNIA ONLY 65 NO 6 5
66 NO 6 6
75 YES 7 5
CO potentiometer 76 YES 7 6
77 YES 7 7
79 YES 7 9 fall sensor (open circuit)
