ELECTRIC SYSTEM
6 -39
Pegaso 650 I.E.
6.16.6 CHANGING THE DASHBOARD BULBS
To change, proceed as follows:
◆ Position the vehicle on the stand.
◆ Remove the front fairing, see 7.1.24 (REMOVING THE
FRONT FAIRING).
◆ Slide out the relevant rubber bulb holder and, where
necessary, replace the bulb.
One bulb under the coolant temperature indicator
(A).
One bulb under the speedometer/odometer (B).
One bulb under the revolution counter (C).
Six bulbs under the warning light panel (D).
Warning
light
Description
6 direction indicators
- fuel reserve
û diagnostics
/ neutral
. engine oil pressure
7 High beam
Release 00/2002-02
- 00
