Use of a new battery (04_15, 04_16, 04_17, 04_18)
CHECK THAT THE CABLE TERMINALS AND BATTERY LEADS ARE:
- IN GOOD CONDITION (NOT CORRODED OR COVERED BY DEPOSITS);
- COVERED BY NEUTRAL GREASE OR PETROLEUM JELLY.
CAUTION
UPON REFITTING, CONNECT THE LEAD TO THE POSITIVE TERMINAL (+) FIRST
AND AFTERWARDS THE LEAD TO THE NEGATIVE TERMINAL (-).
04_15
•
If the rider and passenger saddles have been refitted onto the vehicle, re-
move them again.
•
Install the battery (7) in its seat.
•
Position the positive cable (6) correctly, and fasten it to the positive terminal
(+), tightening the screw (5).
The positive cable (6) must be on top of the battery (7), as shown.
•
Position the negative cable (4) correctly, and fasten it to the negative terminal
(-), tightening the screw (3).
The negative cable (4) must be on top of the battery (7), as shown.
153
