04_27
Front light group (04_27, 04_28)
The headlamp unit uses LED light sources only, and consists of the following modules:
•
two low beam headlight modules (1);
•
one high beam headlight module (2);
•
two DRL modules (3);
•
two turn indicator modules (4);
•
two bending light modules (to assist rider in bends) (5).
04_28
The bending lights are only activated if the low beam headlights are on and once the
vehicle reaches a lean angle of at least 25°.
•
When leaning into a left hand bend, the left hand LED bending assist light
illuminates (A).
•
When leaning into a right hand bend, the right hand LED bending assist light
illuminates (A).
CAUTION
IN THE EVENT OF A MALFUNCTION OF THE HEADLAMP UNIT, CONTACT AN
Official Aprilia Dealer.
04_29
Headlight adjustment (04_29, 04_30, 04_31, 04_32)
NOTE
IN COMPLIANCE WITH LOCAL LEGISLATION, SPECIFIC PROCEDURES MUST
BE FOLLOWED WHEN ALIGNING THE LIGHTS.
164
