(HIGH BEAM HEADLIGHT)
•
Working from underneath the headlamp unit, turn the adjuster screw (3).
TIGHTEN (clockwise) to lower the light beam; LOOSEN (anticlockwise) to
raise the beam.
•
This adjuster screw may be used to adjust the vertical alignment of the high
beam headlight beam.
NOTE
CHECK THAT THE VERTICAL ALIGNMENT OF THE BEAM IS CORRECT.
Rear optical unit
CAUTION
THE TAIL LIGHT ASSEMBLY MUST BE REMOVED, CHECKED AND, IF NECES-
SARY, REPLACED BY AN Authorised Aprilia Dealer.
Rear turn indicators
NOTE
FOR REMOVING, CHECKING AND REPLACING THE REAR INDICATORS,
PLEASE SEE AN Authorised Aprilia Dealership
