APRILIA SCARABEO 125 Service Manual

•
Undo and remove the screw «1» from
both sides.
•
Undo and remove the three screws
«2» and the two screws «3» from both
sides.
•
Undo and remove the two screws «4»
located at the bottom of the footrest,
from both sides.
•
Slide off the footrest.
Side fairings
To remove the front side fairings, proceed as fol-
lows:
•
Open the glove-box.
•
Working from both sides, undo the
screw «1» and the eight screws «2».
SCARABEO 125 - 200 Chassis
CHAS - 187

APRILIA SCARABEO 125 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Fuel System	Carburetor
Transmission	Automatic CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Cooling System	Air cooled
Rear Suspension	Hydraulic shock absorber
Power	8.5 kW
Maximum Torque	7, 000 rpm
