NOTE
INSERT THE BULB IN THE BULB HOLDER SO THAT THE TWO GUIDING PINS
COINCIDE WITH THEIR GUIDES ON THE BULB HOLDER.
NOTE
TIGHTEN THE SCREW «1» CAREFULLY AND LIGHTLY.
03_39
03_40
Rear optical unit (03_39, 03_40, 03_41)
In the taillight there are:
- one tail light/stop light bulb «1»;
- two rear turn indicator bulbs «2».
To replace the bulbs:
•
Remove the tail light glass «3» by undoing the two screws «4».
TAIL LIGHT / STOP LIGHT BULB
•
Remove the tail light lens «5» by undoing the two screws «6».
•
Press the bulb «1» slightly and turn it anticlockwise.
•
Take out the bulb from its fitting.
84
3 Maintenance
