52
use and maintenance Scarabeo 50
5(029,1* 7+( %$77(5<
Carefully read p. 51 (BATTERY).
◆
Make sure that the ignition switch is in
position “
”.
◆
Remove the inspection cover, see p. 45
(REMOVING THE INSPECTION COV-
ER).
◆
Unscrew and remove the screw (1).
◆
Rotate the battery cover (2) downwards.
◆
Withdraw the battery from its box.
◆
Disconnect first the negative cable (–)
and then the positive cable (+).
◆
Disconnect the breather pipe (3).
◆
Remove the battery from its compart-
ment and put it on a level surface in a
cool and dry place.
&+(&.,1*
7+( (/(&752/<7( /(9(/
Carefully read p. 51 (BATTERY).
◆
Remove the battery from its compart-
ment, see p. 52 (REMOVING THE BAT-
TERY).
◆
Make sure that the fluid level is included
between the two “MIN” and “MAX” notch-
es stamped on the battery side.
Otherwise:
◆
Unscrew and remove the element plugs.
Top up with distilled water only.
Do not exceed the “MAX” mark,
since the electrolyte level in-
creases during the recharge.
◆
Top up by adding distilled water.
5(&+$5*,1* 7+( %$77(5<
Carefully read p. 51 (BATTERY).
◆
Remove the battery from its compart-
ment, see p. 52 (REMOVING THE BAT-
TERY).
◆
Unscrew and remove the element plugs.
◆
Check the electrolyte level, see p. 52
(CHECKING THE ELECTROLYTE LEV-
EL).
◆
Connect the battery with a battery charg-
er.
◆
A recharge with an amperage equal to
1/10th of the battery capacity is recom-
mended.
◆
After the recharging operation, check the
electrolyte level again and if necessary
top up with distilled water.
◆
Replace the element plugs.
