APRILIA SHIVER 900 User Manual

•
Remove the ignition coils.
•
Remove the spark plugs using a spe-
cial key.
•
Check the distance between the elec-
trodes using a thread thickness gauge.
CAUTION
DO NOT ATTEMPT IN ANY WAY TO CHANGE THE DIS-
TANCE BETWEEN THE ELECTRODES.
Characteristic
Spark plug electrode gap
0.6 ÷ 0.7 mm (0.024 ÷ 0.028 in)
If the distance between the electrodes is different, replace the spark plug.
•
Make sure the washer is in good conditions.
For installation:
•
With the washer mounted, manually screw the spark plug completely with caution to avoid
damaging the thread.
•
With a suitable key, tighten by performing a 1/2 turn to each spark plug to compress the
washer.
•
Loosen and tighten again the spark plug to the specified torque.
CAUTION
TIGHTEN THE SPARK PLUG CORRECTLY. OTHERWISE, THE ENGINE MAY OVERHEAT AND
GET IRRETRIEVABLE DAMAGED.
USE ONLY THE RECOMMENDED TYPE OF SPARK PLUG, OTHERWISE, ENGINE DURATION
AND PERFORMANCE COULD BE COMPROMISED.
If the distance between the electrodes is different, replace the spark plug.
•
Make sure the washer is in good conditions.
For installation:
•
With the washer mounted, manually screw the spark plug completely with caution to avoid
damaging the thread.
•
With a suitable key, tighten by performing a 1/2 turn to each spark plug to compress the
washer.
Maintenance SHIVER 900
MAIN - 68

APRILIA SHIVER 900 Specifications

General

Displacement	896.1 cc
Transmission	6-speed
Rear Brakes	240 mm disc, single-piston caliper
Engine Type	V-Twin, 4-stroke
Power	70 kW (95.2 hp) @ 8, 750 rpm
Torque	90 Nm at 6, 500 rpm
Fuel System	Electronic fuel injection
Front Suspension	Inverted fork with adjustable preload and rebound damping
Rear Suspension	Aluminum swingarm with adjustable rebound and preload
Front Brakes	Dual 320 mm discs, radial 4-piston calipers
ABS	Standard
Traction Control	Adjustable traction control
Ride Modes	Sport, Touring, Rain
Seat Height	810 mm
Wheelbase	1, 460 mm
Fuel Capacity	15 liters
Dry Weight	199 kg (439 lbs)
