PLANNED MAINTENANCE
WARNING LABEL
138861
QTY. 1
PANEL DECAL
APS 2000 INSTRUCTIONS
6006571
QTY. 1
MOVE ON GREEN
ONLY SIGN
709832
QTY. 1
SAFETY LABELS AND SIGNS
Finished Size: 4-1/8” x 7” 6002986
(972) 466-0707 or 1-800-525-2010
DANGER
6002986B
To avoid injury, before using dock equipment, be certain
you read and understand its operating instructions and
warnings which are printed in the owner's manual and
may be posted on wall. Do not use dock equipment if it
looks broken or does not seem to work right. Tell your
supervisor at once. Use manual wheel chocks on all
trailers if vehicle restraint needs repair.
Death or serious injury may result when trucks
unexpectedly pull away from the dock. Before loading or
unloading, make certain the truck wheels are chocked or
a vehicle restraining device holds the vehicle in place.
Before allowing the vehicle to leave the dock return the
dock leveler to its storage position.
Before chocking wheels or engaging trailer restraint,
dump air from air ride suspensions and set parking
brake.
Failure to follow these instructions could
result in death or serious injury.
Call number above for additional safety labels, or manuals,
or with questions regarding proper use, maintenance, and
repair of dock equipment.
Arc Flash and Shock Hazard
PPE [Personal Protection Equipment] Required
De-energize equipment before
working on or inside.
Do not open cover without appropriate PPE.
Refer to NFPA 70E for PPE requirements.
This panel may contain more than one power source.
Hazardous voltage will cause severe injury or death.
1
1
2
2
3
3
4
4
A A
B B
- CRITICAL QUALITY DIMENSION
TOLERANCES ARE IN INCHES
UNLESS OTHERWISE SPECIFIED
MATERIAL SPECIFICATION
DRAWN
MATERIAL#/PO#
PART DESCRIPTION
DRAWN DATE
JOB/REF NUMBERSCALE
ISSUEPART NUMBER
.X :
0.060
.XX :
0.030
.XXX :
0.010
FRACTIONAL :
1/16
DIAMETER : +0.015 / -0.005
ANGULAR :
1 DEG
B
6013795
SEE NOTES
CONTROL PANEL, APS2000
N/A
N/A
herman.mckinney
11/19/2012
N/A
UOM
INCH
The information contained herein is proprietary and condential to 4Front Engineered Solutions and is to be used solely for the
express purpose of consideration and development of the article described herein and may not be reproduced or disseminated without
the express written permission of 4Front.
EZIS TEEHSTEEHS
B
7
OF
7
- REFERENCE DIMENSION ( )
29
1
50
1
33
1
30
1
31
1
32
1
27
1
LOCATE LABELS APPROXIMATELY AS SHOWN
INSIDE OF DOOR
ARC AND SHOCK
HAZARD LABEL
6002986
QTY. 1
To Next Page
