8.21 Battery info : Get into this item can show all information of battery, including
Voltage, Current, Avg Current, Cycle times, Capacity, Remaining Capacity , Full
Charge Capacity , Temperature, Max Tempt, Min Tempt , Relate ChgSta ,
Absolute ChgSta , Max Uncharge Times , Last Uncharge Times , CorVolt-1.
*These information needs to be supported by battery communication.
9． Error Code define
860C can show warning message, icon shows on the screen, and show error code at
the bottom of the screen, error code from 04~30, definition see the table below.
Error Code Error description Error display
04 Throttle on high position
Display 04H on LOGO position
05 Throttle error
Display 05H on LOGO position
07 High voltage protection
Display 07H on LOGO position
08 Motor’s hall sensor error
Display 08H on LOGO position
09 Phase line of motor error
Display 09H on LOGO position
10 Controller over temperature
Display 10H on LOGO position
11 Motor over temperature
Display 11H on LOGO position
12 Current sensor error
Display 12H on LOGO position
13
Battery’s temperature sensor
error
Display 13H on LOGO position
14 Motor‘s temperature sensor
Display 14H on LOGO position
