Aputure Nova P600c - Fixture Presets and DMX Connection

2.4 Fixture Presets
There are 4 preset buttons under the control box. After setting the light to the
desired output mode, long press any one of the four buttons 1, 2, 3, 4 to start the
process of saving the preset, and use the INT knob to select "Yes/No". Then, you
can use these preset buttons in any mode to activate the mode and content
previously saved to the preset.
- 20 -
Daisy chaining
multiple lights
using DMX
3. Connecting to DMX
3.1 Connect a standard DMX controller
OUTPUT
DMX512
Connecting DMX to
only one Nova P600c
DMX512
OUTPUT
