Aqua Lung SECOND STAGE - Table 5. Checking Specifications

FIRST TO DIVE 15
Table 4. Torque values
N° REFERENCE DESCRIPTION COUPLE
AP2031 Nut (5) 0.5 m.kg.
Table 5. Checking specifications
TEST INSTRUCTIONS SPECIFICATIONS
Leak Test 160 bar < Working pressure < 200 bar No leak
Medium Pressure 160 bar < Working pressure < 200 bar
MP at 9.5 bar ± 0.5 bar: Legend and Legend LX
MP at 8.5 bar ± 0.5 bar: Legend Supreme and Legend LX
Supreme
Opening effort 160 bar < Working pressure < 200 bar
Legend LX: between 2.5 mbar et 3.5 mbar
Legend LX Supreme: between 3.3 and 4.3 mbar
Effort / Flow
MP at 9.5 bar ± 0.5 bar: Legend LX
MP at 8.5 bar ± 0.5 bar: Legend LX
Supreme
15 mbar maxi at 400 L/min
