Simpool Timer Model INSTRUCTION AND MAINTENANCE MANUAL
Programmable digital peristaltic pump ENGLISH
ADSP7000722 rev. 1.0 23/02/2017 50/64
Step 1 - Open the front glass Step 2- Turn the roller clockwise and release the (left) intake ring nut
Step 3 - Remove the tube Step 4 - Release the (right) delivery ring nut and remove it completely
Fig. 14 - Removal of the peristaltic tube
Reassembly of the peristaltic tube
Step 1 - Position the tube and secure it on the left-hand side Step 2 - Insert it in the bell by turning the roller
