Aquatight PH20V - Post-Installation Trial

Recommendation for protecting devices and cable specification
MODEL
PH20V PHC30V PHC45V PHC60V PHC60Vs PHC75Vs
Rated
Current A
15 20 25 40 15 20
Breaker
Rated
Residual
Action
Current mA
30 30 30 30 30 30
Fuse A 15 20 25 40 15 30
Power Cord （mm
2
） 3×2.5 3×4 3×4 3×6 5×2.5 5×4
Signal cable （mm
2
） 3×0.5 3×0.5 3×0.5 3×0.5 3×0.5 3×0.5
※ Above data is subject to modification without notice.
Note: The above data is adapted to power cord ≤ 10 m .If power cord is ＞10 m, wire
diameter must be increased. The signal cable can be extended to 50 m at most.
10
Trial after first installation
Inspection before connecting power supply
- Check the installation of the whole machine and the pipe connections according to the
pipe connecting drawing.
- Check the electric wiring according to the electric wiring diagram, and ground well.
- Make sure no blockage on the air inlet and outlet, or the efficiency of the heater will be
reduced or cause machine to stop operation.
Trial after connecting power supply
- Connect the machine with electric power supply, then relative information will display on
the LED controller.
(For Detail operation of LED controller, please refer to Chapter “Operation guide”.)
- Start the water pump before turning on the Machine to avoid any damage.
Attention:
Always Start the water pump before turning on this machine
Turn off this machine before turnin
g
off the water
p
um
p
.
