| 15 |
16.1 Special Parts
Set for ring terminal lug
Set for connecting fork terminal lug to pipe
Fork terminal lug
M16 or M20 bolt.
Not included in kit
Flat washer M16&M20
(2 units each size)
Included in kit
Serrated washer M16&M20
(2 units each size).
Included in kit
M16 or M20 nut
Not included in kit
Serrated washer
Flat washer M5 screw
