ARAG 463 Series User Manual (English)

Other manuals for ARAG 463 Series

Installation, Use And Maintenance28 pages

Questions and Answers:

B
Briana ElliottAug 17, 2025
What to do if the pressure gauge reading is higher than actual pressure on ARAG Farm Equipment?
- G
  Grace GarrisonAug 17, 2025
  If your pressure gauge reads higher than the actual pressure, it could be due to a malfunctioning pressure gauge (change the pressure gauge), a squashed gasket inside the pressure gauge partially obstructing the passage (slightly loosen the pressure gauge), or undersized passages across the valve and nozzle, leading to a significant pressure drop (choose section valve tubes and hose tails of the correct size).
H
Hailey MillerAug 21, 2025
What to do if the pressure cannot be lowered with the proportional valve switch on the ARAG 463 Farm Equipment?
- L
  lharperAug 21, 2025
  If the pressure cannot be lowered, it might be due to a non-working proportional valve motor. Check the electrical connection: the cable marked “P” must be connected to the proportional valve (yellow or grey collar). Also, the proportional valve drain passage might be clogged (clean the drain passage), or a hydraulic agitator might be connected to the drain passage of the proportional valve (remove the hydraulic agitator and leave the hole open). The drain tube of the proportional valve might be undersized (change the drain tube), or the proportional valve flow rate might be lower than the desired rate setting (change the proportional valve). If the motor is faulty, have the gearmotor inspected at the nearest Service Centre.
M
megan56Aug 25, 2025
What to do if the pressure transducer reading is higher than actual pressure on ARAG Farm Equipment?
- A
  adamsphillipAug 25, 2025
  If the pressure transducer reading is higher than the actual pressure, the transducer might be malfunctioning (change data settings in computer; if problem persists, change transducer) or the passages across the valve and nozzle might be undersized, leading to a significant pressure drop (choose section valve tubes and hose tails of correct size).
J
johncarrAug 28, 2025
How to fix inaccurate adjustment with significant pressure changes on ARAG Farm Equipment?
- L
  Leah BaileyAug 28, 2025
  Inaccurate adjustment with minor switch movements causing significant pressure changes can be caused by a proportional valve not correctly sized for the system (change the proportional valve), insufficient liquid delivery to the control unit (check pump rate and increase pump RPM), or open branches or drain outlets upstream of the control unit.
D
David LongAug 30, 2025
What to do if sections are issuing product when the discharge valve is open on ARAG 463 Farm Equipment?
- C
  Cory WestAug 31, 2025
  If product issues from the section valves when the discharge valve is open, the discharge valve pipe may be blocked (clean drain passage), equipped with a hydraulic agitator (remove hydraulic agitator and leave hole open), or too small (change drain tube). Also, the discharge valve plug gasket may be worn (bring complete unit to the nearest Service Centre for gasket replacement) or there may be chemical product residue on the gaskets and the discharge valve hose tail fitting (clean parts with suitable detergent as indicated in cap. 6 - Maintenance / diagnostics / repairs).
M
marymillerSep 3, 2025
Why are one or more sections not closing correctly on ARAG 463 Farm Equipment?
- K
  Kristy LopezSep 3, 2025
  If one or more sections are not closing correctly, the section valve motor may not be working (check electric connection), the section valve plug gasket may be worn out (change worn gaskets), or there may be chemical residue on the gasket and seat of the section valve hose tail (clean parts with suitable detergent as indicated in cap. 6 - Maintenance / diagnostics / repairs). If the motor is faulty, have the gearmotor inspected at the nearest Service Centre.
T
Tiffany SmithSep 6, 2025
How to handle large pressure fluctuations when closing sections on ARAG 463?
- B
  Brian ElliottSep 7, 2025
  If you're experiencing large pressure fluctuations when one or two sections are closed, the metered by-passes may not be adjusted. Make sure to adjust the metered by-passes.
J
Janet KeithSep 10, 2025
What to do if the operating pressure is not reached when the main valve is opened in my ARAG Control Unit?
- B
  bryan13Sep 10, 2025
  If the operating pressure isn't reached when you open the main valve on your ARAG Control Unit, several factors could be at play. First, ensure that the intakes and outlets are correctly connected. Next, check the maximum pressure valve to make sure it isn't completely unscrewed; adjust it as necessary. Also, verify that the self-cleaning filter is properly closed. A clogged delivery or suction filter can also cause this issue, so clean the respective cartridges. Finally, ensure sufficient liquid is entering the control unit by checking the pump flow rate, increasing pump revs, and confirming there are no open offsets or discharges before the unit.

ARAG 463 Series Specifications

General

Category	Farm Equipment
Type	Sprayer
Boom Width	12 meters
Nozzle Number	24
Sizes	Compact
Materials	Polyethylene tank
Series	463 Series

Summary

Product Description and Intended Use

Intended Use of the Control Unit

Defines the device's design for agricultural machinery and crop spraying applications.

Product Functioning and Components

Manual Control Units: 471 Series Composition

Diagram and component list for manual control units with the 471 SERIES main control valve.

Manual Control Units: 464 Series Composition

Diagram and component list for manual control units with the 464 SERIES main control valve.

Functions of Control Unit Components

Detailed explanation of the function of each component within the control unit.

Installation Procedures and Safety

Safety Regulations for Installation

Crucial safety precautions and guidelines to follow during the installation process.

Installing and Connecting the Control Unit

Instructions and diagrams for physically installing and securing the control unit.

Connecting the Spraying System

Guidance on correctly connecting hoses and system layout for proper operation.

Pre-Operation Settings and Adjustments

Manual Unit Adjustments Before Operation

Step-by-step guide for performing initial adjustments and settings before operating the unit.

Adjusting Maximum Operating Pressure

Procedure for setting the maximum operating pressure, specifically for units with proportional valves.

Using the Control Unit

Calibration of Operating Pressure

Instructions for calibrating the unit's operating pressure for spraying applications.

Calibration of Compensation Cocks

Guide to calibrating compensation cocks to ensure uniform liquid distribution.

Maintenance, Diagnostics, and Troubleshooting

Cleaning the Manual Control Units

Procedures and frequency for cleaning the manual control units and their components.

Cleaning the Filters

Detailed instructions for manual cleaning of the filter cartridge.

Automatic Self-Cleaning Filter Operation

Explanation of the two methods for cleaning self-cleaning filters: continual and regular.

Troubleshooting Constant Pressure Systems

Common problems and solutions for units operating with constant pressure.

Troubleshooting Proportional Valve Systems

Common problems and solutions for units operating with a proportional valve.

Technical Data and Specifications

Valve Pressure vs. Component Correspondence

Table detailing the relationship between valve types, knob colors, and pressure ratings.

Valve Type and Flowrate Correspondence

Data correlating valve types with their respective flow rates and pressure drops.

Proportional Valve Technical Data

Technical specifications for proportional valves, including flow rates and sizes.

Boom Section Valve Technical Data

Technical specifications for boom section valves, including flow rates and sizes.

Disposal, Guarantee, and Compliance

Guarantee Terms and Conditions

Details on the warranty period, coverage, exclusions, and conditions for ARAG products.

Conformity Declaration Information

Information on the declaration of conformity available on the ARAG website.
