MAINTENANCE 12
Cleaning the grills and switch
First, unplug the power chisel. Regularly check to
see if any dust or foreign matter has entered the
grills positioned on the front and back of the
motor or under the switch (as shown in fig.16).
To clean grills and switch use a soft brush to
remove any accumulated dust. Wear safety
glasses when doing this.
Accessories
Accessories available for the Power Chisel
(PCH.FG.030) Starter PACK (pkt of 5).
(PCH.FG.032) Woodcarver pack (pkt of 3)
Spare Parts
(PCH.FG.040) Cam M10 x 1.5 thread pitch with Oil
(PCH.FG.041) Cam M10 x 1.25 thread pitch with Oil
(PCH.FG.042) Cam M14 x 1.5 thread pitch with Oil
(PCH.FG.043) Cam 5/8 UNC thread pitch with Oil
(PCH.FG.050) Service Kit
(PCH.FG.055) Oil refill Pack
Fig.16
