Note: text, diagrams and data are correct at time of printing. In the interests
of continuous improvement of our products, technical specifications are
subject to alteration without prior notice.
5 KNOWING YOUR TOOL
Chisel locking button
Cam
Button spring
Chisel holding
spring
Rear bush
Extension Arm
Lubrication port
Front bush
Cap screws
Felt pad
(oil reservoir)
TECHNICAL SPECIFICATIONS:
Max. SPM:
Power:
Rating:
Weight:
Vibration emission:
Noise emission:
12,000 rpm @ spindle
5.8A ~ 700 Watt
230-240V, AC, 50-60Hz (PCH.FG.300) AUS
120V, AC, 60Hz (PCH.FG.300.20) US
1.83
Kg
3.338 m/s2
100dB(A)
CE-Declaration of Conformity:
We declare under our sole responsibility that this product is in conformity with the CE
standards.
AUST. APPROVAL SGSEA/120903
