1. Remove the Power Chisel from its box.
Inspect to ensure that no damage has occurred
during shipping. If damaged, report to the retailer
immediately.
2. The Power Chisel is packaged with two acces-
sory chisels. Remove a chisel from the box, wipe
off the sticky coating and insert into the exten-
sion arm as shown in fig:1. When the chisel is
inserted correctly it should snap firmly into place.
The bevel of the chisel should fall away from the
tool body.
3. Before plugging in, ensure that the on/off
switch is in the OFF position (Fig.2).
* Place 2 to 3 drops of oil in the lubrication port
as shown in fig.3 using the 15ml oil bottle sup-
plied.
* Wipe off the sticky coating on the chisels
before using.
KNOWING YOUR TOOL (cont’d) 6
Fig.1
Fig.2
Unpacking and Assembly
Fig.3
Arm
Clamping groove
Chisel bevel
Tool body
Chisel
Mounting plate
