arcelik BEKO G91632NE User Manual

SBS COSMOS
REFRIGERATOR 10.01.2014 / REV NO: 03
42
Sensitivity: Public
220V AC
INPUT
Line
KN5-1
KN5
INPUT
Neutral
KN5-3
OUTPUT
Compressor
KN5-4
OUTPUT
Frz Defrost Heater
KN5-5
OUTPUT
FF Heater
KN5-6
OUTPUT
Ionizer
KN5-7
OUTPUT
Main Water Valve
KN5-8
OUTPUT
Water Pipe Heater
KN5-9
OUTPUT
Water Valve
KN5-10
OUTPUT
Ice Valve
KN5-11
INPUT
Dispenser Switch
KN5-13
220V AC
OUTPUT
Ice Crusher Motor
KN7-1
KN7
12V DC
OUTPUT
Ice Motor
KN4-7.8
KN4
Ice lid motor
KN4-3.4
Ice selection motor
KN4-1.2
12V DC
OUTPUT
Freezer Fan
KN10-1.20.3
KN10
Condenser Fan
KN10-4.50.6
FF Fan
KN10-7
Blue Ray
KN10-11
FF Illumination
KN10-12.13
FRZ Illumination
KN10-14
GND
KN10-9.15
5V DC
OUTPUT
Display Inputs-Outputs
KN12-1.7
KN12
