arcelik BEKO K70520NE User Manual (English)

Claudia WhiteJul 25, 2025

What to do if E2 Fridge Evaporator Error is flashing on my arcelik BEKO K70520NE?

M
Matthew CollierJul 25, 2025
If you see the E2 error flashing on your Arcelik Refrigerator, start by checking the cables connected to the control board sensor socket (KN6) pins no. 3 and 4. If the cables are properly connected, use a multimeter to measure the sensor resistance from the control board KN6 pins no 3 and 4. The measured value should be between 5K. If the sensor resistance is not appropriate, replace the control board, as the sensor cannot be replaced since it is in polyurethane.

Brand	arcelik
Model	BEKO K70520NE
Category	Refrigerator
Language	English

Brand

arcelik

Model

BEKO K70520NE

General Safety Warnings

HCA Warning

Warning about R600a gas and potential fire hazards during usage and transport.

Water Dispenser Safety

Guidelines for products with water dispensers, including pressure and water type.

Intended Use

Specifies domestic use, not for commercial use, and product lifespan.

Child Safety

Precautions regarding children, packaging materials, and product interaction.

WEEE Directive and Disposal

Information on recycling and safe disposal of electrical waste according to WEEE.

Package Information

Details on recyclable packaging materials and local collection points.

Disposing of Waste Product

Instructions for proper disposal of the appliance and its components at end-of-life.

Attaching a Different Plug

Guide for correctly connecting appliance wires to a new plug based on color codes.

Product Overview

Overall Dimensions

Technical specifications and measurements for the K70520 and K70530 models.

Exploded Views

Diagrams showing product components at 90° and maximum opening angles.

Installation

Transportation Instructions

Guidelines for safely moving and transporting the appliance.

Installation Instructions

Procedures and conditions for installing the refrigerator correctly.

Appropriate Location for Installation

Advice on choosing a suitable place for the appliance considering ventilation and heat sources.

Electrical Connection

Instructions for connecting the appliance to the power supply safely and correctly.

Floor Balance Adjustment

Steps to ensure the refrigerator is level for stable operation.

Water Connection for Ice Machine

Steps for connecting the appliance to a water supply for ice making.

Use of Product

General Operation Principle

Explanation of how the microprocessor-controlled no-frost system works.

Operating the Product

Inner Display and Controls

Explanation of the inner display, icons, and control buttons.

Display Indicators and Modes

Details on temperature display, modes like vacation, and economy.

Gas Flow Diagram and Parts

Cooling System Operation

Explanation of the refrigeration circuit's components and function.

FF Defrost Process

How the forced defrost cycle operates for the freezer compartment.

Compressor Operation

Conditions and parameters for compressor activation and deactivation.

Quick Freeze Function

How to activate and the parameters of the quick freeze mode.

Component List and Principles

Enumerates key electronic components and their basic functions.

Electronic and Control System

Compressor Details

Specifications and technical data for the compressor unit.

Fan Motor Specifications

Details on fridge and freezer compartment fan motors.

Condenser Fan Motor

Specifications for the condenser fan motor.

Temperature Sensor Data

Resistance variance table for temperature sensors.

Electronic Control System

Component Descriptions

Detailed explanations of various sensors, heaters, and control cards.

U2 Control Board

Location and function of the main control board.

U2 Board Port Connections

Diagram and description of the U2 board's input/output ports.

Freezer Drain Heater

Function and operation of the heater for the freezer drain zone.

FF Ambient Heater

Role of the ambient heater in preventing freezing in the FF compartment.

Defrost Heater Function

How the defrost heater melts ice in the freezer evaporator.

Electric Circuit Diagram

Schematic representation of the appliance's electrical connections.

Troubleshooting

Refrigerator Not Running

Troubleshooting flowchart for when the appliance does not operate.

Fridge Compartment Condensation

Reasons and solutions for condensation inside the fridge.

Compressor Not Running

Troubleshooting steps when the compressor is not operational.

Frequent or Long Running Time

Explains why the refrigerator might run continuously.

Temperatures Too Low

Diagnosing and fixing issues with excessively low temperatures.

Noisy Operation

Identifying causes and solutions for unusual noises from the refrigerator.

Identifying Refrigerator Sounds

Diagnosing normal and abnormal sounds from the appliance.

Inner Wall Moistening

Causes and remedies for moisture accumulation inside the fridge.

Exterior Condensation

Explains external condensation and how to address it.

Doors Not Closing Properly

Troubleshooting steps for doors that do not seal correctly.

Sensor Error Diagnostics

Identifying and resolving issues related to sensor errors.

Initial Operation and Power Failure

Understanding initial startup and power interruption behavior.

E2 Fridge Evaporator Sensor Error

Detailed flowchart for diagnosing and resolving the E2 sensor error.

Attachment/Detachment Processes of Parts

Upper Hinge Lid Removal

Step-by-step guide to remove the upper hinge lid.

Door Removal Procedure

Instructions for safely detaching the refrigerator doors.

Door Handle Removal

Steps to remove door handles from the appliance.

Changing Door Opening Direction

Guide on how to reverse the door swing direction.

Board Cover and Electronic Boards

Instructions for accessing and removing internal electronic components.

Fridge Compartment Illumination

Steps to remove the internal lighting assembly and LED board.

Sensor Cover Removal

Procedure for removing the sensor cover.

Crisper Sliding Rail Removal

How to detach the sliding rails for the crisper drawers.

Second Floor Crisper Rails

Instructions for removing the sliding rails for the second floor crisper.

Crisper Cover Removal

Steps to detach the crisper drawer cover.

Second Floor Crisper Cover

Procedure for removing the second floor crisper cover.

Fridge Compartment Evaporator Cover

How to remove the cover for the fridge compartment evaporator.

Freezer Compartment Evaporator Cover

Instructions for detaching the freezer compartment evaporator cover.

Thermostat Setting Box

Procedure for removing and attaching the thermostat setting box.

Reed Sensor Board Removal

Steps to detach the reed sensor board assembly.

Above-Body Pediment Removal

How to detach the upper body pediment and its connection sheet.

Upper Hinge Removal

Steps for removing the upper hinge, referencing another step.

Lower Hinge and Adjustable Foot

Procedure for removing the lower hinge and adjustable foot.

Compressor Rear Cover Removal

Steps to detach the cover protecting the compressor at the rear.

Water Valve Disassembly

Instructions for disassembling the water valve group and related pipes.

Evaporation Container Removal

How to detach the evaporation container.

Terminal Box Cover Removal

Procedure for removing the terminal box cover.

Run Capacitor Removal

Steps to detach the run capacitor.

Filter Box Removal

Procedure for removing the filter box.

Thermic Relay Group Removal

Instructions for detaching the thermic relay group.

Maintenance and Cleaning

Cleaning Procedures

Guidelines for regular cleaning of the refrigerator's interior and exterior.

Avoiding Bad Odors

Tips to prevent and eliminate unpleasant smells within the appliance.

Protecting Plastic Surfaces

How to prevent damage to plastic components from oils and spills.
