arcelik BEKO G91633NE User Manual

SBS COSMOS REFRIGERATOR 07.11.2018 / REV NO: 01
75
Sensitivity: Public
3
 It is found at the lower covers of the fresh food and freezer doors.
 Remove 2 pcs of 4x13 inox magnetic screws by attaching the star bit to the chargeable
gun, as shown in Picture 1.
 Remove the parts shown in Pictures 2 and 3.
12.23. Main board cover
Used service number: 827
 Remove 5 pcs of PT 4x12 screws by using a Phillips screwdriver.
 Service warning plate is on the inner part of the cover.
BEARING
WITH
STOPPER
DOOR
PULLER
SPRING
PLASTIC
STOPPER
METAL
STOPPER

arcelik BEKO G91633NE Specifications

General

Appliance placement	Freestanding
Door hinge	Right
Reversible doors	Yes
Noise level	39 dB
Fridge interior light	Yes
Lamp type	LED
No Frost (fridge)	Yes
Fridge door balconies	Yes
Egg balcony	Yes
Bottle rack	Yes
No Frost (freezer)	Yes
Ice cube tray	Yes
Fresh zone compartment	Yes
Energy efficiency class	A+
Height	185 cm
Climate class	SN, N, ST, T
