Archgard OPTIMA 30 - 1 - Page 12

OPTIMA 30-1 12
SWITCH WIRING
ON-OFF SWITCH
WIRING
SPILL SWITCH
WIRING
WIRE CLIP
GROMMET
SLIDING FLUE ADAPTER
INSTALLATION INSTRUCTIONS Cont...
SPILL SAFETY
SWITCH
SLIDING FLUE
ADAPTER
FLUE PULL AND
FASTENING BAR
SCREW HERE AFTER
INSTALLATION AND CUT
OFF EXCESS BAR
WARNING:
Maximum clear-
ance between
front of unit and
front of flue pipe
is 15 1/2”
9” to 15 1/2”
