OPTIMA 30-1 17
Set the thermostat, if present, to the lowest level. Press slightly and turn the control
knob clockwise
3to the OFF position and wait 5 minutes; thus allowing any gases
to escape which may have accumulated in the combustion chamber.
Note: LP gases do not vent upward. Then follow step 2 and 3 to establish pilot.
OPERATION INSTRUCTIONS Cont..
Press and turn control knob counterclockwise 4 to ON position.
Release knob. If pilot should go out, turn the control knob to OFF position and
repeat steps 1, 2 and 3.
Note: The control valve is equipped with an internal safety interlock. You must
leave at “off” position for about 5 minutes before lighting pilot again.
Press slightly and turn control knob counterclockwise 4to PILOT position;
depress control knob and light pilot by repeatedly pressing the sparker. Venting of
air may take place prior to flow of pilot gases. Once flame is established, hold knob
depressed for approximately 60 seconds.
AUTOMATIC VALVE START-UP PROCEDURE
1.
2.
3.
4.
5.
7.
Turn flame and heat adjustment knob to the desired comfort level from HIGH to LOW.
8.
SHUT-DOWN PROCEDURE TO PILOT FLAME
To turn off the main burner only, set the thermostat to the lowest setting or turn
switch to OFF. Press and turn the knob clockwise
3to PILOT position.
Press and turn the knob clockwise 3 to the OFF position.
COMPLETE SHUT-DOWN PROCEDURE
6.
Turn thermostat to the desired comfort level or turn ON/OFF switch to the ON position.
Sparker
Control Knob
Flame and Heat Adjustment Knob
Pilot Adjustment Screw
Control indicator
Attach on-off
switch leads
here
