Optima 72
46
REPLACING CONVECTION BLOWER
Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can
cause improper and dangerous operation. Verify proper operation after servicing
.
This appliance, when installed, must be electrically grounded in accordance with local codes
or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the
Canadian Electrical code, CSA C22.1.
NOTES:
• Ensure that the main power and breaker system is turned OFF before removing the fan.
• Make sure the fireplace has been turned off and is cool to the touch.
• Mark all wires to be removed for proper reassembly.
CAUTION: Wiring errors cause improper and dangerous operation.
1. The convection blower is located at the bottom of the appliance at the back. Loosen the 3
screws holding the blower.
2. Lift the blower out and disconnect the wires from the blower.
3. Repeat above steps to install new fan.
Please see Wiring Diagram on page 24 of this manual.
