Description of the device
Loudspeaker
Front camera
Volume buttons
Power connector
ON/OFF button
1
2
3
Mini-HDMI video output
(1)
Micro-USB port
Micro-USB host port
(2)
Microphone
Micro-SD card slot
Headphone jack
Reset button
Flash light
Back camera
4
5
6
7
8
9
10
11
12
13
14
(1)
With optional Mini-HDMI to HDMI cable.
(2)
Connect a keyboard, a mouse or a mass storage USB device using
the optional USB host adapter
