Arctic Cat 300 DVX 2012 - SECTION 6 - DRIVE SYSTEM;BRAKE SYSTEM

6-1
6
SECTION 6 - DRIVE SYSTEM/
BRAKE SYSTEM
TABLE OF
CONTENTS
Drive System/Brake System.................................... 6-2
Front Drive Actuator/Differential Lock...................... 6-2
Front Differential...................................................... 6-3
Drive Axles ............................................................ 6-16
Rear Gear Case .................................................... 6-19
Hub........................................................................ 6-20
Hand Brake Lever/Master Cylinder Assembly....... 6-21
Hydraulic Brake Caliper......................................... 6-23
Troubleshooting Drive System............................... 6-26
Troubleshooting Brake System.............................. 6-26
