! WARNING
Indicates a potential hazard that could
result in a serious injury or death.
11
Location of Parts and Controls
(DVX 250)
1. Battery
2. Headlights
3. Hand Brake Lever
4. Fuel Valve
5. Choke Lever
6. Seat Lock Lever
7. Auxiliary Brake Pedal
8. Shift Lever
9. Brake Lever Lock
KM186A
KM187A
KM174A
11. Key Switch
12. Reverse Override Button
13. Throttle Limiter
14. Throttle Lever
15. Tool Kit Location
16. Taillight/Brakelight
17. Operatorís Manual
Location
18. Headlight OFF/HI/LO Switch
19. Engine Starter Button
