Active Riding
Shifting (DVX)
This ATV has a single-range automatic transmission with reverse. To
shift the ATV, follow these steps:
1. To engage the forward gear
from neutral,
outward and forward.
2. To engage reverse gear from
neutral, move the shift lever
outward and rearward into the R
position.
Shifting (2x4)
This ATV has a dual-range automatic transmission with reverse. To
shift the ATV, follow these steps:
2. To engage the low range from
high range, move the shift lever
outward and forward.
!CAUTION
Always come to a complete stop before attempting to shift from
one gear to the other. Always shift on level ground, or engage the
brake lever lock before shifting into forward gear or into reverse.
! WARNING
Do not start the engine or operate this ATV with the V-belt cover
removed. Severe injury could result.
KM203A
KM124A
move the shift
lever
actuate any brake
lever and
1. To engage1the
neutral,
ward and forward.
move the shift
lever out-
actuate any brake
and
high range from
lever
22
28
