1 The Adapter
As it turned out that Arduino users have a need of a quick and easy way to securely build projects as well as adding
small circuits for extra control, the Nano Screw Terminal Adapter was developed to assist in building such robust
projects, without the need of soldering.
1.1 Compatible boards
Product name SKU
Min
voltage
Max
voltage
Arduino® Nano 33 IoT ABX00027/ABX00032 5 V 18 V
Arduino® Nano 33 BLE Sense ABX00031/ABX00035 5 V 18 V
Arduino® Nano BLE ABX00030/ABX00028 5 V 18 V
Arduino® Nano Every ABX00033/ABX00028 5 V 18 V
Arduino® Nano RP2040 connect ABX00052/ABX00053 5 V 18 V
Arduino® Nano Every ABX00033/ABX00028 7 V 18 V
Arduino® Nano A000005 7 V 12 V
Note! Please turn to each board's datasheet for further information
about power and their capacity.
1.2 Application Examples
Motor Driver Design: Evaluate motor drivers and other smaller circuits on the prototyping area
External debugging: All the standard Nano pins are accessible via both breadboard compatible pin headers as
well as the screw terminals. This allows for direct probing of signals via a multimeter or oscilloscope while the
device is under operation.
Rapid solution development: Quickly connect to external circuitry with pin headers or screw terminals to evaluate
new ideas quickly. Rapidly prototype circuits and evaluate various Nano boards to choose the best option for your
application.
