Arduino ASX00037 User Manual

Arduino® Nano Screw Terminal Adapter
7 / 10 Arduino® Nano Screw Terminal Adapter Modified: 29/09/2022
3 Mechanical Information
3.1 Board Outline and Mounting Holes
Ø3mm
51mm
70mm
63mm
41mm
4mm
5mm
4mm
5mm
R2mm
Board layout
4 Certifications
4.1 Declaration of Conformity CE DoC (EU)
We declare under our sole responsibility that the products above are in conformity with the essential requirements
of the following EU Directives and therefore qualify for free movement within markets comprising the European
Union (EU) and European Economic Area (EEA).

Arduino ASX00037 Specifications

General

Brand	Arduino
Model	ASX00037
Category	Adapter
Language	English
