Arduino® Nano Screw Terminal Adapter
5 / 10 Arduino® Nano Screw Terminal Adapter Modified: 29/09/2022
2 Functional Overview
2.1 Board Topology
2.1.1 Top
Board topology Top
Ref. Description Ref. Description
J17 HLE-115-02-F-DV-Footprint-2 J19 HLE-115-02-F-DV-Footprint-2
J18 CONNECTOR MORS.CS16v J20 CONNECTOR MORS.CS 16v
2.1.2 Bottom
Board topology bottom
