Arduino® Nicla Voice

10 / 25 Arduino® Nicla Voice Modiﬁed: 05/01/2023

4.2 Board Topology

4.2.1 Connectors Topology

NiclaHeader-B

NiclaHeader-A

BOTTOMTOP

Nicla Voice Topology- Components

Ref. Description Ref. Description

J1 Nicla Header A J2 Nicla Header B

J3 Battery Pads J4 Battery Connector (BM03B-ACHSS)

J5 ESLOV Connector (SM05B-SRSS) J6 External Microphone (FH33J-4S)

J7 Micro USB-AB (ZX62-AB)
