27
10. Technical data sheet
General information
Active Bike Active Sport
Frame aluminium alloy aluminium alloy
Sunspensions - front and rear
Speed L1: ≤ 6km/h
L2: ≤ 20km/h
L3: ≤ 25km/h
(Max speed) *
L1: ≤ 6km/h
L2: ≤ 20km/h
L3: ≤ 25km/h
(Max speed) *
Maximum slope ** 21% 30%
Brakes Front and rear disc brakes Electronic front brake and
rear disc brake
Tyres 20" front and 16" rear with
inner tube
front and rear 10” tubeless
Maximum load 120 kg 140 kg
Rider Check the current legislation in your country
Operating temperature -5 °C/ 45 °C -5 °C/ 45 °C
Protection level IPX4 IP55
Charging time approx 5/6 hours approx. 7 hours
Autonomy** up to 35km up to 80km
Electrical system
Motor 350W Brushless 500W Brushless
Display LED Built-in LED
Battery 36V 10Ah 375Wh 54V 12.5Ah 675Wh
Low voltage protection 31V ±0.5V 37.5V ±0.5V
KERS Ye s Yes
Lights Front and rear LEDs Front, rear and lateral LEDs
Features - Sensor-activated direction
indicators
Dimensions and weight
Net weight 19 kg 24 kg
Gross weight 23 kg 30 kg
Open item dimensions 1650 x 600 x 1180mm 1307 x 520 x 1275mm
Closed item dimensions 1650 x 230 x 735mm 1307 x 520 x 560mm
Packaging dimensions 1405 x 230 x 580mm 1280 x 285 x 785mm
* Always respect the highway code and the regulations in force in the country where the electric
scooter is used.
** Subject to variations based on the rider's weight, on the road conditions and on the temperature.
