36
(6) Recharging
● Be sure to charge the specified amount of
refrigerant in liquid state using the service port
of the wide tube service valve. The proper
amount is listed on the unit's nameplate.
When the entire amount cannot be charged all at
once, charge gradually while operating the unit
in Cooling Operation.
● When charging with a refrigerant cylinder, use
an electronic scale for charging refrigerant. In
this case, if the volume of refrigerant in the
cylinder becomes less than 20% of the fully-
charged amount, the composition of the
refrigerant starts to change. Thus, do not use
the refrigerant if the amount in the charging
cylinder is less than 20%.
Also, charge the minimum necessary amount to
the charging cylinder before using it for charging
the air conditioning unit.
Example:
In case of charging refrigerant to a unit requiring
0.76Kg using a capacity of a 10Kg cylinder, the
minimum necessary amount for the cylinder is:
0.76 + 10 × 0.20 = 2.76Kg
For the remaining refrigerant, refer to the
instructions of the refrigerant manufacturer.
● If using a charging cylinder, transfer the
specified amount of liquid refrigerant from the
refrigerant cylinder to the charging cylinder.
Prepare an evacuated charging cylinder
beforehand.
Do not use the refrigerant if the amount in
the charging cylinder is less than 20%.
