2. SPECIFICATIONS
2-1. Unit Specifications
Outdoor Unit AE4MI91AH
Type 4-room multi outdoor unit
Number of connectable indoor units 4
Maximum capacity of connected indoor units kW 15.4
Maximum capacity of operating indoor units kW 15.4
Power Source 220–240V ~ 50Hz 220V ~ 60Hz
Voltage rating 230V 220V
Performance Cooling Heating Cooling Heating
Capacity kW 9.0 (1.2 - 10.5) ### (1.7 - 10.8) 9.0 (1.2 - 10.5) ### (1.7 - 10.8)
BTU/h 30,700 34,100 30,700 34,100
Air circulation (High)
m
3
/h
2,800 2,800
Electrical Rating Cooling Heating Cooling Heating
Available voltage range V 198 ~ 264 198 ~ 242
Running amperes A 8.8 (Max.15.5) 9.7 (Max.16.5) 8.8 (Max.15.5) 9.7 (Max.16.5)
Power input W 1,940 2,170 1,940 2,170
Power factor % 96 97 96 97
C.O.P. W/W 4.64 4.61 4.64 4.61
Starting amperes A 12.7 12.7
Features
Controls Microprocessor
Fan speeds Auto (Hi, Lo)
Compressor Twin Rotary (DC inverter)
Refrigerant / Amount charged at shipment g R410A / 4,000
Refrigerant control Electric Expansion Valve
Operation sound Hi dB-A 53 54 53 54
Refrigerant tubing connections Flare type
Max. allowable tubing length per unit m 30
Refrigerant Narrow tube mm (in.)
6.35(1/4) × 4
tube diameter Wide tube mm (in.)
9.52(3/8) × 3
mm (in.)
12.7(1/2) × 1
Dimensions & Weight
Unit dimensions Height mm 880
Width mm 940
Depth mm 340
Package dimensions Height mm 981
Width mm 1,016
Depth mm 440
Weight Net kg 90
Shipping kg 92
Shipping volume
m
3
0.44
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
2. Rating conditions are:
Cooling : Indoor air temperature 27°C D.B. / 19°C W.B.
Outdoor air temperature 35°C D.B. / 24°C W.B.
Heating : Indoor air temperature 20°C D.B.
Outdoor air temperature 7°C D.B. / 6°C W.B.
Remarks:
1. The value shown in performance section and electrical rating section above are based on the following unit
combination. For other combination of indoor units, please refer to the “Unit Combination Table” in this manual.
Indoor unts: SAP-KMRV93GJH 2 units
(Outdoor unit: SAP-CMRV3143GJH 1 unit )
10.0 10.0
Remarks:
1. The values shown in performance section and electrical rating section above are based on the following unit
combination. For other combination of indoor units, please refer to the “Unit Combination Table” in this manual.
Indoor units : AWMI28AHL4 units
(Outdoor unit : AE4MI91AH 1 unit)
2. Rating conditions are:
Cooling : Indoor air temperature 27°C D.B. / 19°C W.B.
Outdoor air temperature 35°C D.B. / 24°C W.B.
Heating : Indoor air temperature 20°C D.B.
Outdoor air temperature 7°C D.B. / 6°C W.B.

Argo AE4MI91AH Specifications

General

Brand	Argo
Model	AE4MI91AH
Category	Air Conditioner
Language	English
