2-2. Major Component Specifications
2-2-1. Outdoor Unit
Outdoor Unit AE4MI91AH
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Control PCB / HIC PCB / Filter PCB POW-CM5A1-C-T / CR-HIC50A2-C-T / POW-CM5B1-C-T
Compressor
Type DC Twin Rotary (Hermetic)
Compressor model C-9RVN273H0W 80867080
Compressor oil … Amount cc FVC68S … 1900
Coil resistance (Ambient temp. 25°C) Ω R – S: 0.169
S – T: 0.169
T – R: 0.169
Safety devices
CT (Peak current cut-off control) YES
Compressor discharge temp. control YES
Operation cut-off control in abnormal ambient temp. —
Run capacitor µF —
VAC —
Crankcase heater 25W 240V
Fan & Fan Motor
Type Propeller
Q’ty … Dia. mm 1 … ø460
Fan motor model … Q’ty KFC6S-61C3PA-C … 1
No. of poles … rpm (220V, High) 6 … 712
Nominal output W 60
Coil resistance (Ambient temp. 20°C) Ω BRN – WHT: 66.53
WHT – YEL: 33.95
YEL – PNK: 12.50
Safety devices Type Thermal protector
Operating temp. Open °C 130 ± 8
Close °C 79 ± 15
Run capacitor µF 5
VAC 440
Heat Exchanger Coil
Coil Aluminum plate fin / Copper tube
Rows 2
Fin pitch mm 1.4
Face area m
2
0.630
External Finish Acrylic baked-on enamel finish
