Argo AE4MI91AH - Page 42

Single-room operation
Indoor unit
Indoor Unit Capacity (kW)
Conbination
Room A Room B Room C Room D Total Performance Power Input (W) Current (A)
Min. - Max. Min. - Max.
2.8 Heating 4.0 4.0 1,530 7.2
1.8 - 5.4 1,170 - 1,760
Cooling 2.8 2.8 1,270 6.0
1.3 - 3.2 990 - 1,360
3.6 Heating 4.8 4.8 1,660 7.8
1.9 - 6.3 1,190 - 1,910
Cooling 3.6 3.6 1,420 6.7
1.4 - 3.6 1,010 - 1,430
5.0 Heating 7.1 7.1 2,040 9.4
2.0 - 7.8 1,200 - 2,150
Cooling 5.0 5.0 1,690 8.0
1.5 - 5.8 1,030 - 1,850
7.0 Heating 8.0 8.0 2,150 9.6
2.0 - 8.8 1,290 - 2,230
Cooling 7.0 7.0 1,880 8.9
1.5 - 8.1 1,120 - 2,040
Two-room operation
Indoor unit
Indoor Unit Capacity (kW)
Conbination
Room A Room B Room C Room D Total Performance Power Input (W) Current (A)
Min. - Max. Min. - Max.
2.8+2.8 Heating 4.00 4.00 8.0 2,030 9.3
1.6 - 9.0 800 - 2,170
Cooling 2.80 2.80 5.6 1,710 8.1
1.1 - 6.7 540 - 1,870
2.8+3.6 Heating 4.00 4.80 8.8 2,090 9.4
1.7 - 9.0 820 - 2,170
Cooling 2.80 3.60 6.4 1,780 8.4
1.3 - 7.6 670 - 1,920
3.6+3.6 Heating 4.80 4.80 9.6 2,130 9.5
1.7 - 9.8 820 - 2,170
Cooling 3.60 3.60 7.2 1,840 8.7
1.4 - 8.1 720 - 1,940
2.8+5.0 Heating 3.60 6.40 10.0 2,160 9.6
1.7 - 10.6 820 - 2,170
Cooling 2.80 5.00 7.8 1,880 8.8
1.4 - 8.1 720 - 1,940
3.6+5.0 Heating 4.00 6.00 10.0 2,170 9.7
1.7 - 10.6 820 - 2,170
Cooling 3.60 5.00 8.6 1,920 9.0
1.4 - 10.5 720 - 2,380
2.8+7.0 Heating 3.35 6.65 10.0 2,170 9.7
1.7 - 10.8 820 - 2,350
Cooling 2.55 6.45 9.0 1,940 8.8
1.2 - 10.5 620 - 2,380
Outdoor Unit AE4MI91AH
2.8: AWMI28AHL H
3.6: AWMI38AHL
5.0: AWMI50AHL
7.0: AWMI70
AHL
NOTE
4-Room Outdoor Unit Combination Table
39
Indoor Unit
Combination
Indoor Unit
Combination
2-room operation
