3
A
B
C
D
Dimensions Inlet &
Outlet Pipe
Size
Approximate
Shipping Wt.
A B C D E
14⅝” 18⅝ “ 9¹/₃₂ 14⅜” 16¹⁵/₃₂ 1¼ NPT 70 lbs.
"AT" SERIES BOILER DIMENSIONS
E
