HOW TO REMOVE THE FILTER
1.Grasp both ends of the air intake grille and pull to open
it.
2.Hold the air filter by the tab and pull it upward. Clean the
air filter.
3.When replacing the filter, make sure that the FRONT
mark is facing you. Reinsert the filter into place and close
the air intake grille.
2
1
GB
AIR FILTER
The filter behind the air intake grille should be checked and
cleaned at least once every two weeks. (AW-FC MODELS)
HOW TO REMOVE THE FILTER
1. Grasp both ends of the air intake grille and pull it towards
you and up.
2. Push the filter up slightly, and then pull it down. Clean the
air filter.
Air intake
grille
Insert into the groove on the unit
Air filter
Air intake grille
Air filter
HOW TO REPLACE THE FILTER
1. With the «FRONT» mark facing you, slide the filter up
into the unit and then lower the handler into the groove
on the unit.
2. After installing the filter, press the locations marked by
the arrows ( ) and close the air intake grille.
AW MODELS
11
FILTER CLEANING
Use a vacuum cleaner to remove light dust. If there is
sticky dust on the filter, wash the filter in lukewarm, soapy
water, rinse it in clean water, and dry it.
1.Remove the screw on each side out of the latch using a
screwdriver.
2.Press on the two latches of the air intake grille with your
thumbs in the direction of the arrow to open the grille.
3.Open the air intake grille downward.
4.Remove the air filter from the air intake grille. Clean the
air filter.
5.Insert the filter correctly again inside the grille, close the
grille letting the latches slide toward the outside and fix
again the latch with the screw on both sides.
The air filter should be cleaned at least once every six
months or more frequently; it depends on the real operation
conditions.
HOW TO REMOVE THE FILTER
LATCH
SCREW
AIR INTAKE GRILLE
AIR FILTER
AS MODELS
FC MODELS
