Argo AW735CLF User Manual

GB
8
VERTICAL (with remote control unit)
Press the FLAP button to select the flap function:
HORIZONTAL (manual) - Only for AW-FC models
The horizontal air flow can be adjusted by moving the
vertical vanes to the left or right, as indicated in the following
figures.
ADJUSTING THE AIR FLOW DIRECTION
Do not move the flap with your hands when the air
conditioner is running.
CAUTION
Left
Vertical vane
Right
FC MODELS
AW MODELS
AS MODELS
FLAPS
l
Use the FLAP button on the remote control to adjust
the position of the flap. If you move the flap by hand,
the factual flap position and the flap position on the
remote control may no longer match. If this should
happen, shut off the unit, wait for the flap to close,
and then turn on the unit again; the flap position will
now be normal again.
l
Do not have the flap pointed down during cooling
operation. Condensation may begin to form around the
air vent and drip down.
CAUTION
AW MODELS
FC MODELS
VERTICAL VANE
Fixed:
six
position
Continous
oscillations
Automatically
oscillations
Up
Down
Flap
Air outlet
grille
DEFLETTORE
NOTES
l
The flap automatically closes when the unit
is off.
l
When the unit starts in heating operation,
the fan speed will be low and the flap will be
in the 4 position until the air being blown
out of the unit begins to warm. Once the air
warms up, the flap position and fan speed
change to the settings specified with the
remote control.
TIMER SETTING PROCEDURE.
l
Press four times the TIMER SEL
button.The 1 HOUR TIMER mark will
appear on the display.
CANCELLATION PROCEDURE
l
Press the ON/OFF button to turn the air conditioner off.
l
Wait for the indoor unit to stop operating.
l
Press the ON/OFF button again to turn the air conditioner
on.
SETTING THE 1 HOUR TIMER
This function causes the unit to operate for one hour at the
set conditions, regardless of whether the unit is on or off.
