GALLIUM : 3. Cable housing installation (continued)
Front & rear derailleur: Remove
the cable guide cap (4h) under
the bottom bracket. Pass the
cables inside the downtube
until they come out under the
bottom bracket, than in the
cable guide (4d).
Fix the cable guide cap under
the bottom bracket with the
5mm screw (1.5 Nm).
It’s better to install the cables
before installing the bottom
bracket, crank and fork.
4d
4h
