Argon 18 RADON - Frame Inspection Guide

3
RADON : 1. Frame inspection
Parts installed on the frame Description Screw Tork Detail
type Nm
1 Seatpost, Ø 31.6mm Seatpost Carbon paste
2 Rear derailleur hanger Screw (2) 3mm 4Nm Loctite
3 Bottle cage Screw (4) 4mm 3Nm Grease
4 Seatpost collar Clamp 4mm 6Nm Grease
5 Bottom bracket cable guide Screw 5mm 3Nm Grease
When assembling a new frame, be sure to check if the following parts are assembled correctly.
