ARGON18 E-112 - Frame Inspection

4
E-112 : 1. Frame inspection
Parts installed on the frame Description Screw Torque Detail
type Nm
1 Front derailleur hanger Screw (2) 3mm 4Nm Loctite
2 Rear derailleur hanger Screw (4) 3mm 4Nm Loctite
3 Bottle cage Screw (2) 4mm 3Nm Grease
4 Bottom bracket cover Screw (1) 5mm 2Nm Grease
When assembling a new frame, be sure to check if the following parts are assembled correctly.
